The CX7805 series of three-terminal positive regulator are available in the TO-220 package and with several fixed output voltages, making them useful in a wide range of applications. Each type employs internal current limiting, thermal shut down and safe operating area protection, making it essentially indestructible. If adequate heat sinking is provided, they can deliver over 1.2A output current. Although designed primarily as fixed voltage regulators, these devices can be used with external components to obtain adjustable voltages and currents.
• Output Current up to 1.2A
• Thermal Overload Protection
• Short Circuit Protection
• Output Transistor Safe Operating Area Protection
• Output Voltages : 5V
家电,电表
需要详细的PDF规格书请扫一扫微信联系我们,还可以获得免费样品以及技术支持!
三端稳压器(Three-terminal Positive Regulator ) | ||||||||
Part No. | Features | VIN | VOUT | Accu. | IQ | IOUT(Max.) | Package | Application |
Three-terminal 1.2A Positive Voltage Regulator | Max 35V | 5V | ±4% | Max 6mA | 1.2A | TO220 | 家电,电表 | |
Three-terminal Positive Voltage Regulator | Max 35V | 5V | ±2% | 2mA | 100mA | SOT89-3 TO92 | 家电,电表 | |
Three-terminal Positive Voltage Regulator | Max 30V | 5V | ±4% | Max 5.5mA | 100mA | SOT89-3 TO92 | 家电,电表 | |
Three-terminal Positive Voltage Regulator | Max 35V | 5V | ±4% | 4mA | 500mA | TO252 | 家电,电表 | |
Three-terminal Positive Voltage Regulator | Max 35V | 5V | ±2% | 5mA | 1A | TO252 | 家电,电表 | |
High Current Adjustable Voltage Regulator | Max 37V | ADJ | ±4% | 50μA | 1A | TO220 | STB | |
High Current Adjustable Voltage Regulator | Max 40V | ADJ | ±4% | 46μA | 1.5A | TO220 TO252 TO263 | STB | |
High Current Adjustable Voltage Regulator | Max 40V | ADJ | ±4% | 46μA | 1.5A | TO220 TO252 TO263 | STB | |
1A-Low-Dropout Regulator. Max Surge Supply Voltage Is 60V(t≤100ms) | Max 26V | 5,12V | ±3% | 10mA | 1A | SOT223 TO252 TO220 TO263 | 电表 | |
100mA-Low-Dropout Regulator | Max 30V | 2.5,3,3.3,3.6,5V | ±2% | 120μA | 100mA | TO92 TO252 SOP8 DIP8 | 电表 | |
100mA-Low-Dropout Regulator | Max 30V | 2.5,3,3.3,3.6,5V | ±2% | 120μA | 100mA | TO92 TO252 SOP8 DIP8 | 电表 |
