Primary-Side Control LED Driv有源PFC的原边控制LED驱动控制器，The CXLE8756 is a primary-side control offline flyback controller with active power factor correction. It is especially designed for LED lighting system

The CXLE8756 is a primary-side control offline flyback controller with active power factor correction.

It is especially designed for LED lighting system. The CXLE8756 controls the LED current accurately

without using an opto-coupler, which can significantly simplify the design of LED lighting system.

Utilizing an on-chip multiplier, the CXLE8756 achieves high power factor over wide line and load ranges.

The multi-protection function largely enhances the safety and reliability of the system, including over

 voltage protection; short circuit protection, LED open protection, cycle-by-cycle current limit, VCC UVLO

 and over-temperature protection.

 󰁺Real current control without secondary

 󰁺feedback circuit

 󰁺 High current accuracy of line regulation

󰁺 Active power factor correction

󰁺 Low harmonic content

󰁺 High efficiency over wide operating range

󰁺 Cycle-by-cycle current limit

󰁺 Input over-voltage protection

󰁺 LED short protection

󰁺 LED open protection

󰁺 Over-temperature protection

󰁺 8-Pin SOP package
