400KHz 60V 3A Switching Current Boost / Buck-Boost / Inverting DC/DC Converter CXSU6311 regulator is a wide input range, current mode, DC/DC converter which is capable of generating either positive o

The CXSU6311 regulator is a wide input range, current mode, DC/DC converter which is capable of generating either positive or negative output voltages. It can be configured as either a boost, flyback, SEPIC or inverting converter. The CXSU6311 built in N-channel power MOSFET and fixed frequency oscillator, current-mode architecture results in stable operation over a wide range of supply and output voltages. The CXSU6311 regulator is special design for portable electronic equipment.

„ Wide 3.6V to 32V Input Voltage Range „

 Positive or Negative Output Voltage Programming with a Single Feedback Pin „

Current Mode Control Provides Excellent Transient Response „

 1.25V reference adjustable version „

Fixed 400KHz Switching Frequency „

Maximum 3A Switching Current „

SW PIN Built in Over Voltage Protection „

Excellent line and load regulation „

EN PIN TTL shutdown capability „

 Internal Optimize Power MOSFET „

High efficiency up to 92% „

Built in Frequency Compensation „

Built in Soft-Start Function „

Built in Thermal Shutdown Function „

Built in Current Limit Function „

Available in TO252-5L package„

„  Automotive and Industrial Boost / Buck-Boost / Inverting Converters „

  Portable Electronic Equipment
